Butyl rubber steel plate waterstop can effectively prevent construction joints from water leakage and seepage, and play a buffer role for various forces. The steel plate putty waterstop is a composite waterstop product of polymer material with excellent comprehensive performance and galvanized plate. The main material of rubber-plastic putty is the rubber-plastic material with excellent aging resistance, which has strong self-adhesive and does not flow at high temperature in summer. It is not brittle at low temperature in winter; it has excellent water, acid and alkali resistance and aging resistance; it has long service life, product itself and good environment.
Working principle of butyl rubber steel plate waterstop: waterstop plays a role of waterstop and water separation in deformation joint or induced joint of large reservoir structure. During construction, the water stop shall be ensured to be in the designed position through the cooperative action of formwork clamping and reinforcement. The waterstop in the bottom plate and the pool wall shall be connected as a whole, the steel plates at the joint shall be connected by rivets, and the rubber shall be connected by hot melting. The blocks separated by waterstop during construction must be staggered. If block a is constructed first, block B adjacent to it must be constructed after block a concrete is formed. After the integral forming, the water inside and outside the pool is blocked by the steel edge neoprene waterstop, and the deformation resistance is enhanced by adding steel sheets to the rubber waterstop, so as to improve the water resistance after deformation.
Product composition of butyl rubber steel plate waterstop: steel plate putty waterstop is a waterstop product composed of polymer material with excellent comprehensive performance and galvanized plate. The main material of rubber-plastic putty is butyl rubber with excellent aging resistance, which has strong self-adhesive, and does not flow at high temperature in summer. It is not brittle at low temperature in winter, and has excellent water resistance, acid and alkali resistance and aging resistance; long service life, product itself, good environment.. There are 0.4 or 0.6mm steel plates in the middle to ensure that they can withstand certain bending and pressure.
